Camera
3K CMOS sensor
Maximum resolution 2960 × 1665
Sensitivity 0.01 lux @ (F1.2, AGC on), 0 lux with IR illumination
Electronic shutter speed PAL: from 1/25 to 1/50,000 sec; NTSC: 1/30 to 1/50,000 sec
Day/Night Mode Mechanical IR-cut filter
Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 75°, Rotate: 0 to 360°
Transmission Standard PAL / NTSC
Lens
Lens Type Fixed lens 2.8mm and 3.6mm
Focal Length
and Angle of View
2.8mm, Horizontal: 107°, Vertical: 64°, Diagonal: 129°
3.6mm, Horizontal: 83°, Vertical: 48°, Diagonal: 102°
Lens Mount M12
Illumination
Illumination Type White Light Illumination, IR Illumination
Range illumination
IR illumination: up to 30 m
White light illumination: up to 20 m
Image settings Brightness, sharpness, intelligent IR illumination
Frame rate
TVI: 3K @ 20 fps, 4 MP @ 25 / 30 fps, 1080p @ 25 / 30 fps
AHD: 5 MP @ 20 fps, 4 MP @ 25 / 30 fps
CVI: 4 MP @ 25 / 30 fps
CVBS: PAL / NTSC
Day / Night IR and white light illumination
Wide Dynamic
Range (WDR) Digital WDR
Image enhancement Yes
White balance Auto / Manual
AGC Yes
Interfaces
Video output Switchable TVI / AHD / CVI / CVBS
Main
Material Metal
Dimensions 80 × Ø 85.1 mm (3.1 × Ø 3.4″)
Weight Approx. 300 g
Operating conditions -40 to +60 °C, humidity: 90% or less (non-condensing)
Protocol HIKVISION-C
Language English
Power
DC 12 V ± 25 %
* It is recommended to use a separate power adapter for each
camera.
Power consumption Max. 2.9 W
Certifications
Protection standards IP67
